8-Bit, 1.5-GSPS Analog-to-Digital Converter (ADC)

Pricing (USD)

Quantity	Unit Price
1 — 99	391.762
100 — 249	360.67
250 — 999	310.922
1,000 +	274.23

The above prices are for reference only.

Specifications

Manufacturer	Analog Devices Inc.
Product Category	Analog to Digital Converters - ADC
RoHS	Y
Series	AD7794
Mounting Style	SMD/SMT
Package / Case	TSSOP-24
Resolution	24 bit
Number of Channels	6 Channel
Sampling Rate	470 S/s
Input Type	Differential
Interface Type	3-Wire, SPI
Architecture	Sigma-Delta
Reference Type	External, Internal
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 125 C
Packaging	Reel
Height	1.05 mm
Input Voltage	+/- 2.5 V
Length	7.8 mm
Number of Converters	1 Converter
Width	4.4 mm
Brand	Analog Devices
Development Kit	EVAL-AD7794EBZ
Gain Error	+/- 10 uV
INL - Integral Nonlinearity	+/- 15 ppm
Number of ADC Inputs	6 Input
Operating Supply Voltage	5 V
Pd - Power Dissipation	2.5 mW
Product Type	ADCs - Analog to Digital Converters
Sample and Hold	No
Factory Pack Quantity	2500
Subcategory	Data Converter ICs
Unit Weight	0.007478 oz

For more information, please refer to datasheet

Documents

ADC081500CIYB/NOPB Datasheet

More Information

The ADC081500 is a low power, high performance CMOS analog-to-digital converter that digitizes signals to 8 bits resolution at sample rates up to 1.7 GSPS. Consuming a typical 1.2 W at 1.5 GSPS from a single 1.9 Volt supply, this device is ensured to have no missing codes over the full operating temperature range. The unique folding and interpolating architecture, the fully differential comparator design, the innovative design of the internal sample-and-hold amplifier and the self-calibration scheme enable a very flat response of all dynamic parameters beyond Nyquist, producing a high 7.3 ENOB with a 748 MHz input signal and a 1.5 GHz sample rate while providing a 10-18 B.E.R. Output formatting is offset binary and the LVDS digital outputs are compatible with IEEE 1596.3-1996, with the exception of an adjustable output offset voltage between 0.8V and 1.2V.
