ADC08DJ3200AAV Texas Instruments - Yeehing Electronics
8-Bit, Dual 3.2-GSPS or Single 6.4-GSPS, RF-Sampling Analog-to-Digital Converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1093.68 |
| 100 — 249 | 1006.88 |
| 250 — 999 | 868.0 |
| 1,000 + | 765.58 |
The above prices are for reference only.
Specifications
| Manufacturer | Analog Devices Inc. |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | AD4002 |
| Mounting Style | SMD/SMT |
| Package / Case | MSOP-10 |
| Resolution | 18 bit |
| Number of Channels | 1 Channel |
| Sampling Rate | 2 MS/s |
| Input Type | Pseudo-Differential/Single-Ended |
| Interface Type | 3-Wire, QSPI, SPI |
| Architecture | SAR |
| Reference Type | External |
| Analog Supply Voltage | 1.8 V |
| Digital Supply Voltage | 1.71 V to 5.5 V |
| SNR - Signal to Noise Ratio | 95 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Packaging | Tube |
| Number of Converters | 1 Converter |
| Type | Precision |
| Brand | Analog Devices |
| Development Kit | EVAL-AD4002FMCZ |
| DNL - Differential Nonlinearity | 0.5 LSB |
| Gain Error | 10 LSB |
| INL - Integral Nonlinearity | 3.2 LSB |
| Product Type | ADCs - Analog to Digital Converters |
| Reference Voltage | 5.1 V |
| SFDR - Spurious Free Dynamic Range | 122 dB |
| SINAD - Signal to Noise and Distortion Ratio | 95 dB |
| Factory Pack Quantity | 50 |
| Subcategory | Data Converter ICs |
| THD - Total Harmonic Distortion | - 125 dB |
For more information, please refer to datasheet
Documents
| ADC08DJ3200AAV Datasheet |
More Information
The ADC08DJ3200 device is an RF-sampling, giga-sample, analog-to-digital converter (ADC) that can directly sample input frequencies from DC to above 10 GHz. In dual-channel mode, the ADC08DJ3200 can sample up to 3200 MSPS and up to 6400 MSPS in single-channel mode. Programmable tradeoffs in channel count (dual-channel mode) and Nyquist bandwidth (single-channel mode) allow development of flexible hardware that meets the needs of both high channel count or wide instantaneous signal bandwidth applications. Full-power input bandwidth (–3 dB) of 8.0 GHz, with usable frequencies exceeding the –3-dB point in both dual- and single-channel modes, allows direct RF sampling of L-band, S-band, C-band, and X-band for frequency agile systems.
