ADC12J4000NKE Texas Instruments - Yeehing Electronics
12-Bit, 4.0-GSPS, RF Sampling Analog-to-Digital Converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | None |
| 100 — 249 | None |
| 250 — 999 | None |
| 1,000 + | None |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | ADS1278 |
| Mounting Style | SMD/SMT |
| Package / Case | HTQFP-64 |
| Resolution | 24 bit |
| Number of Channels | 8 Channel |
| Sampling Rate | 144 kS/s |
| Input Type | Single-Ended |
| Interface Type | SPI |
| Architecture | Sigma-Delta |
| Reference Type | External |
| Analog Supply Voltage | 4.75 V to 5.25 V |
| Digital Supply Voltage | 1.65 V to 2.2 V |
| SNR - Signal to Noise Ratio | 111 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 105 C |
| Packaging | Reel |
| Features | Daisy-Chainable |
| Height | 1 mm |
| Length | 10 mm |
| Number of Converters | 8 Converter |
| Power Consumption | 530 mW |
| Width | 10 mm |
| Brand | Texas Instruments |
| DNL - Differential Nonlinearity | +/- 1 LSB |
| INL - Integral Nonlinearity | +/- 0.0012 % FSR |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 1.65 V to 3.6 V, 4.75 V to 5.25 V |
| Pd - Power Dissipation | 785 mW |
| Product Type | ADCs - Analog to Digital Converters |
| Factory Pack Quantity | 1000 |
| Subcategory | Data Converter ICs |
| Unit Weight | 0.009108 oz |
For more information, please refer to datasheet
Documents
| ADC12J4000NKE Datasheet |
More Information
The ADC12J4000 device is a wideband sampling and digital tuning device. Texas Instruments giga-sample analog-to-digital converter (ADC) technology enables a large block of frequency spectrum to be sampled directly at RF. An integrated DDC (Digital Down Converter) provides digital filtering and down-conversion. The selected frequency block is made available on a JESD204B serial interface. Data is output as baseband 15-bit complex information for ease of downstream processing. Based on the digital down-converter (DDC) decimation and link output rate settings, this data is output on 1 to 5 lanes of the serial interface.
