ADC32RF42IRMPT Texas Instruments - Yeehing Electronics
Dual-Channel, 14-Bit, 1.5-GSPS RF-Sampling Analog-to-Digital Converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1152.678 |
| 100 — 249 | 1061.196 |
| 250 — 999 | 914.824 |
| 1,000 + | 806.87 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | ADS6445 |
| Mounting Style | SMD/SMT |
| Package / Case | VQFN-64 |
| Resolution | 14 bit |
| Number of Channels | 4 Channel |
| Sampling Rate | 125 MS/s |
| Input Type | Differential |
| Interface Type | I2C |
| Architecture | Pipeline |
| Reference Type | External, Internal |
| Analog Supply Voltage | 3.3 V |
| Digital Supply Voltage | 3 V to 3.6 V |
| SNR - Signal to Noise Ratio | 73.7 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Reel |
| Features | High Performance |
| Height | 0.88 mm |
| Length | 9 mm |
| Number of Converters | 4 Converter |
| Output Type | LVDS |
| Power Consumption | 1.68 W |
| Width | 9 mm |
| Brand | Texas Instruments |
| Development Kit | ADS6445EVM |
| DNL - Differential Nonlinearity | +/- 2.5 LSB |
| ENOB - Effective Number of Bits | 11.7 Bit |
| INL - Integral Nonlinearity | +/- 5 LSB |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 3 V to 3.6 V |
| Pd - Power Dissipation | 1.8 W |
| Product Type | ADCs - Analog to Digital Converters |
| SFDR - Spurious Free Dynamic Range | 83 dB |
| SINAD - Signal to Noise and Distortion Ratio | 72.3 dB |
| Factory Pack Quantity | 2000 |
| Subcategory | Data Converter ICs |
| Unit Weight | 0.008021 oz |
For more information, please refer to datasheet
Documents
| ADC32RF42IRMPT Datasheet |
More Information
The ADC32RF42 device is a 14-bit, 1.5-GSPS, dual-channel, analog-to-digital converter (ADC) that supports RF sampling with input frequencies up to 4 GHz and beyond. Designed for high signal-to-noise ratio (SNR), the ADC32RF42 delivers a noise spectral density of –151.8 dBFS/Hz as well as dynamic range and channel isolation over a large input frequency range. The buffered analog input with on-chip termination provides uniform input impedance across a wide frequency range and minimizes sample-and-hold glitch energy.
