Texas Instruments
ADS1258MPHPTEP
ADS1258MPHPTEP
Regular price
$14.11 USD
Regular price
Sale price
$14.11 USD
Unit price
per
Couldn't load pickup availability
ADS1258MPHPTEP Texas Instruments - Yeehing Electronics
Enhanced product 16-channel 24-bit analog-to-digital converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 30.846 |
| 100 — 249 | 27.419 |
| 250 — 999 | 22.54 |
| 1,000 + | 14.11 |
The above prices are for reference only.
Specifications
| Manufacturer | Analog Devices Inc. |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | AD7177-2 |
| Mounting Style | SMD/SMT |
| Package / Case | TSSOP-24 |
| Resolution | 32 bit |
| Number of Channels | 4 Channel |
| Sampling Rate | 10 kS/s |
| Input Type | Differential/Single-Ended |
| Interface Type | 3-Wire, SPI |
| Architecture | Sigma-Delta |
| Reference Type | External, Internal |
| Analog Supply Voltage | 5 V |
| Digital Supply Voltage | 2.5 V to 5.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 105 C |
| Packaging | Tube |
| Number of Converters | 1 Converter |
| Output Type | Digital |
| Type | Low Noise ADC |
| Brand | Analog Devices |
| Shutdown | No Shutdown |
| Moisture Sensitive | Yes |
| Pd - Power Dissipation | 136 mW |
| Product Type | ADCs - Analog to Digital Converters |
| Reference Voltage | 2.5 V |
| Settling Time | 100 us |
| Factory Pack Quantity | 62 |
| Subcategory | Data Converter ICs |
| Unit Weight | 0.007478 oz |
For more information, please refer to datasheet
Documents
| ADS1258MPHPTEP Datasheet |
More Information
The ADS1258 is a 16-channel (multiplexed), low-noise, 24-bit, delta-sigma () analog-to-digital converter (ADC) that provides single-cycle settled data at channel scan rates from 1.8k to 23.7k samples per second (SPS) per channel. A flexible input multiplexer accepts combinations of eight differential or 16 single-ended inputs with a full-scale differential range of 5 V or true bipolar range of ±2.5 V when operating with a 5-V reference. The fourth-order delta-sigma modulator is followed by a fifth-order sinc digital filter optimized for low-noise performance.
