ADS1258MRTCTEP Texas Instruments - Yeehing Electronics
Enhanced product 16-channel 24-bit analog-to-digital converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 30.846 |
| 100 — 249 | 27.419 |
| 250 — 999 | 22.54 |
| 1,000 + | 14.11 |
The above prices are for reference only.
Specifications
| Manufacturer | Analog Devices Inc. |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | AD7858 |
| Mounting Style | SMD/SMT |
| Package / Case | SOIC-24 |
| Resolution | 12 bit |
| Number of Channels | 8 Channel |
| Sampling Rate | 200 kS/s |
| Input Type | Pseudo-Differential/Single-Ended |
| Interface Type | 3-Wire, I2C, SPI |
| Architecture | SAR |
| Reference Type | External, Internal |
| SNR - Signal to Noise Ratio | 71 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Tube |
| Height | 2.35 mm |
| Input Voltage | 3 V/5 V |
| Length | 15.6 mm |
| Number of Converters | 1 Converter |
| Power Consumption | 25 mW |
| Type | S/H ADC |
| Width | 7.6 mm |
| Brand | Analog Devices |
| DNL - Differential Nonlinearity | +/- 1 LSB |
| Gain Error | +/- 4 LSB |
| INL - Integral Nonlinearity | +/- 1 LSB |
| Moisture Sensitive | Yes |
| Number of ADC Inputs | 8 Input, 4 Input |
| Operating Supply Voltage | 5 V |
| Pd - Power Dissipation | 33 mW |
| Product Type | ADCs - Analog to Digital Converters |
| Sample and Hold | Yes |
| Factory Pack Quantity | 31 |
| Subcategory | Data Converter ICs |
| Unit Weight | 0.038731 oz |
For more information, please refer to datasheet
Documents
| ADS1258MRTCTEP Datasheet |
More Information
The ADS1258 is a 16-channel (multiplexed), low-noise, 24-bit, delta-sigma () analog-to-digital converter (ADC) that provides single-cycle settled data at channel scan rates from 1.8k to 23.7k samples per second (SPS) per channel. A flexible input multiplexer accepts combinations of eight differential or 16 single-ended inputs with a full-scale differential range of 5 V or true bipolar range of ±2.5 V when operating with a 5-V reference. The fourth-order delta-sigma modulator is followed by a fifth-order sinc digital filter optimized for low-noise performance.
