ADS5403IZAY Texas Instruments - Yeehing Electronics
12-Bit, 500-MSPS Analog-to-Digital Converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 142.68 |
| 100 — 249 | 129.15 |
| 250 — 999 | 125.46 |
| 1,000 + | 86.10 |
The above prices are for reference only.
Specifications
| Manufacturer | Maxim Integrated |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | MAX1249A |
| Mounting Style | SMD/SMT |
| Package / Case | QSOP-16 |
| Resolution | 10 bit |
| Number of Channels | 2 Channel/4 Channel |
| Sampling Rate | 133 kS/s |
| Input Type | Differential/Single-Ended |
| Interface Type | SPI |
| Architecture | SAR |
| Reference Type | External |
| SNR - Signal to Noise Ratio | 64 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Reel |
| Height | 1.55 mm |
| Length | 4.98 mm |
| Number of Converters | 1 Converter |
| Width | 3.99 mm |
| Brand | Maxim Integrated |
| DNL - Differential Nonlinearity | +/- 1 LSB |
| INL - Integral Nonlinearity | +/- 0.5 LSB |
| Operating Supply Voltage | 2.7 V to 5.25 V |
| Pd - Power Dissipation | 667 mW |
| Product Type | ADCs - Analog to Digital Converters |
| Factory Pack Quantity | 2500 |
| Subcategory | Data Converter ICs |
| Part # Aliases | MAX1249A |
| Unit Weight | 0.010159 oz |
For more information, please refer to datasheet
Documents
| ADS5403IZAY Datasheet |
More Information
The ADS5403 is a high linearity single channel 12-bit, 500 MSPS analog-to-digital converter (ADC) easing front end filter design for wide bandwidth receivers. The analog input buffer isolates the internal switching of the on-chip track-and-hold from disturbing the signal source as well as providing a high-impedance input. Optionally the output data can be decimated by two. Designed for high SFDR, the ADC has low-noise performance and outstanding spurious-free dynamic range over a large input-frequency range. The device is available in a 196pin BGA package and is specified over the full industrial temperature range (–40°C to 85°C).
