ADS5404IZAY Texas Instruments - Yeehing Electronics
Dual-Channel, 12-Bit, 500-MSPS Analog-to-Digital Converter (ADC)
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 247.95 |
| 100 — 249 | 224.438 |
| 250 — 999 | 218.025 |
| 1,000 + | 149.62 |
The above prices are for reference only.
Specifications
| Manufacturer | Analog Devices Inc. |
| Product Category | Analog to Digital Converters - ADC |
| RoHS | Y |
| Series | AD9629 |
| Mounting Style | SMD/SMT |
| Package / Case | LFCSP-32 |
| Resolution | 12 bit |
| Number of Channels | 1 Channel |
| Sampling Rate | 80 MS/s |
| Input Type | Differential |
| Interface Type | Parallel, SPI |
| Architecture | Pipeline |
| Reference Type | External, Internal |
| SNR - Signal to Noise Ratio | 71.4 dB |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Reel |
| Height | 0.83 mm |
| Input Voltage | 2 Vp-p |
| Length | 5 mm |
| Number of Converters | 1 Converter |
| Power Consumption | 85 mW |
| Type | S/H ADC |
| Width | 5 mm |
| Brand | Analog Devices |
| DNL - Differential Nonlinearity | 0.3 LSB |
| Gain Error | - 1.5 %FSR |
| INL - Integral Nonlinearity | +/- 0.35 LSB |
| Moisture Sensitive | Yes |
| Number of ADC Inputs | 1 Input |
| Operating Supply Voltage | 1.8 V |
| Pd - Power Dissipation | 114 mW |
| Product Type | ADCs - Analog to Digital Converters |
| Sample and Hold | Yes |
| Factory Pack Quantity | 1500 |
| Subcategory | Data Converter ICs |
For more information, please refer to datasheet
Documents
| ADS5404IZAY Datasheet |
More Information
The ADS5404 is a high linearity dual channel 12-bit, 500 MSPS analog-to-digital converter (ADC) easing front end filter design for wide bandwidth receivers. The analog input buffer isolates the internal switching of the on-chip track-and-hold from disturbing the signal source as well as providing a high-impedance input. Optionally the output data can be decimated by two. Designed for high SFDR, the ADC has low-noise performance and outstanding spurious-free dynamic range over a large input-frequency range. The device is available in a 196-pin BGA package and is specified over the full industrial temperature range (–40°C to 85°C).
