ADS5409IZAY Texas Instruments - Yeehing Electronics

Dual-Channel, 12-Bit, 900-MSPS Analog-to-Digital Converter (ADC)

Pricing (USD)

Quantity	Unit Price
1 — 99	444.005
100 — 249	401.901
250 — 999	390.418
1,000 +	267.93

The above prices are for reference only.

Specifications

Manufacturer	Analog Devices Inc.
Product Category	Analog to Digital Converters - ADC
RoHS	Y
Series	AD7490
Mounting Style	SMD/SMT
Package / Case	LFCSP-32
Resolution	12 bit
Number of Channels	16 Channel
Sampling Rate	1 MS/s
Input Type	Single-Ended
Interface Type	SPI
Architecture	SAR
Reference Type	External
SNR - Signal to Noise Ratio	69.5 dB
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Packaging	Reel
Height	0.83 mm
Input Voltage	2.5 V/5 V
Length	5 mm
Number of Converters	1 Converter
Type	S/H ADC
Width	5 mm
Brand	Analog Devices
Development Kit	EVAL-AD7490SDZ
DNL - Differential Nonlinearity	- 0.95 LSB/1.5 LSB
Gain Error	+/- 2 LSB
INL - Integral Nonlinearity	+/- 1 LSB
Moisture Sensitive	Yes
Number of ADC Inputs	16 Input
Operating Supply Voltage	5 V
Pd - Power Dissipation	12.5 mW
Product Type	ADCs - Analog to Digital Converters
Sample and Hold	Yes
Factory Pack Quantity	1500
Subcategory	Data Converter ICs
Unit Weight	2.391575 oz

For more information, please refer to datasheet

Documents

ADS5409IZAY Datasheet

More Information

The ADS5409 is a high linearity dual channel 12-bit, 900 Msps analog-to-digital converter (ADC) easing front end filter design for wide bandwidth receivers. The analog input buffer isolates the internal switching of the on-chip track-and-hold from disturbing the signal source as well as providing a high-impedance input. Optionally the output data can be decimated by two. Designed for high SFDR, the ADC has low-noise performance and outstanding spurious-free dynamic range over a large input-frequency range. The device is available in a 196pin BGA package and is specified over the full industrial temperature range (–40°C to 85°C).
