ADS5463IPFP Texas Instruments - Yeehing Electronics

12-bit 500-MSPS analog-to-digital converter (ADC)

Pricing (USD)

Quantity	Unit Price
1 — 99	190.543
100 — 249	172.474
250 — 999	167.546
1,000 +	114.98

The above prices are for reference only.

Specifications

Manufacturer	Analog Devices Inc.
Product Category	Analog to Digital Converters - ADC
RoHS	Y
Series	LTC2284
Mounting Style	SMD/SMT
Package / Case	QFN-64
Resolution	14 bit
Number of Channels	2 Channel
Sampling Rate	105 MS/s
Input Type	Differential/Single-Ended
Interface Type	Parallel
Architecture	Pipeline
Reference Type	External, Internal
Analog Supply Voltage	3 V
Digital Supply Voltage	3 V
SNR - Signal to Noise Ratio	71.7 dB
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Packaging	Tube
Type	High Speed
Brand	Analog Devices
Shutdown	Shutdown
Development Kit	DC851A-S, DC851A-T
DNL - Differential Nonlinearity	0.6 LSB
FPBW - Full Power Bandwidth	575 MHz
Gain Error	0.5 %/FS
INL - Integral Nonlinearity	1.5 LSB
Pd - Power Dissipation	540 mW
Product Type	ADCs - Analog to Digital Converters
SFDR - Spurious Free Dynamic Range	90 dB
SINAD - Signal to Noise and Distortion Ratio	70.5 dB
Factory Pack Quantity	40
Subcategory	Data Converter ICs
Unit Weight	0.023986 oz

For more information, please refer to datasheet

Documents

ADS5463IPFP Datasheet

More Information

The ADS5463/ADS54RF63 is a 12-bit, 500-/550-MSPS analog-to-digital converter (ADC) that operates from both a 5-V supply and 3.3-V supply, while providing LVDS-compatible digital outputs. This ADC is one of a family of 12-, 13-, and 14-bit ADCs that operate from 210 MSPS to 550 MSPS. The ADS5463/ADS54RF63 input buffer isolates the internal switching of the onboard track and hold (T&H) from disturbing the signal source while providing a high-impedance input.
