ADS54J54IRGCT Texas Instruments - Yeehing Electronics

Quad-Channel, 14-Bit, 500-MSPS Analog-to-Digital Converter (ADC)

Pricing (USD)

Quantity	Unit Price
1 — 99	512.292
100 — 249	471.634
250 — 999	406.581
1,000 +	358.60

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Analog to Digital Converters - ADC
RoHS	Y
Series	ADS5292
Mounting Style	SMD/SMT
Package / Case	HTQFP-80
Resolution	12 bit
Number of Channels	8 Channel
Sampling Rate	80 MS/s
Input Type	Differential
Interface Type	Serial
Architecture	Pipeline
Analog Supply Voltage	1.8 V
Digital Supply Voltage	1.8 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Packaging	Reel
Features	Low Power
Number of Converters	8 Converter
Output Type	LVDS
Power Consumption	376 mW
Brand	Texas Instruments
DNL - Differential Nonlinearity	+/- 0.8 LSB
ENOB - Effective Number of Bits	11.3 Bit
Moisture Sensitive	Yes
Operating Supply Voltage	1.7 V to 1.9 V
Product Type	ADCs - Analog to Digital Converters
SFDR - Spurious Free Dynamic Range	85 dB
Factory Pack Quantity	1000
Subcategory	Data Converter ICs
Unit Weight	0.013355 oz

For more information, please refer to datasheet

Documents

ADS54J54IRGCT Datasheet

More Information

The ADS54J54 is a low power, wide bandwidth 14-bit 500 MSPS quad channel analog-to-digital converter (ADC). It supports the JESD204B serial interface with data rates up to 5 Gbps supporting 1 or 2 lanes per ADC. The buffered analog input provides uniform input impedance across a wide frequency range while minimizing sample-and-hold glitch energy. A sampling clock divider allows more flexibility for system clock architecture design. The ADS54J54 provides excellent spurious-free dynamic range (SFDR) over a large input frequency range with very low power consumption. Optional 2x Decimation Filter provides high-pass or low-pass filter modes.
