Dual-Channel, 16-Bit, 1.0-GSPS Analog-to-Digital Converter (ADC)

Pricing (USD)

Quantity	Unit Price
1 — 99	1031.873
100 — 249	949.979
250 — 999	818.947
1,000 +	722.31

The above prices are for reference only.

Specifications

Manufacturer	Maxim Integrated
Product Category	Analog to Digital Converters - ADC
RoHS	Y
Series	MAX192B
Mounting Style	SMD/SMT
Package / Case	SSOP-20
Resolution	10 bit
Number of Channels	8 Channel
Sampling Rate	133 kS/s
Input Type	Differential/Single-Ended
Interface Type	SPI
Architecture	SAR
Reference Type	External, Internal
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Packaging	Reel
Height	1.78 mm
Length	7.33 mm
Number of Converters	1 Converter
Width	5.38 mm
Brand	Maxim Integrated
DNL - Differential Nonlinearity	+/- 1 LSB
INL - Integral Nonlinearity	+/- 1 LSB
Operating Supply Voltage	4.75 V to 5.25 V
Pd - Power Dissipation	640 mW
Product Type	ADCs - Analog to Digital Converters
Reference Voltage	4.096 V
Factory Pack Quantity	2000
Subcategory	Data Converter ICs
Part # Aliases	MAX192B
Unit Weight	0.016000 oz

For more information, please refer to datasheet

Documents

ADS54J60IRMP Datasheet

More Information

The ADS54J60 is a low-power, wide-bandwidth, 16-bit, 1.0-GSPS, dual-channel, analog-to-digital converter (ADC). Designed for high signal-to-noise ratio (SNR), the device delivers a noise floor of –159 dBFS/Hz for applications aiming for highest dynamic range over a wide instantaneous bandwidth. The device supports the JESD204B serial interface with data rates up to 10 Gbps, supporting two or four lanes per ADC. The buffered analog input provides uniform input impedance across a wide frequency range while minimizing sample-and-hold glitch energy. Each ADC channel optionally can be connected to a wideband digital down-converter (DDC) block. The ADS54J60 provides excellent spurious-free dynamic range (SFDR) over a large input frequency range with very low power consumption.
