ADS54J69IRMP Texas Instruments - Yeehing Electronics
Dual-Channel, 16-Bit, 500-MSPS Analog-to-Digital Converter (ADC)
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 578.084 |
100 — 249 | 532.205 |
250 — 999 | 458.797 |
1,000 + | 404.66 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Analog to Digital Converters - ADC |
RoHS | Y |
Series | ADS8354 |
Mounting Style | SMD/SMT |
Package / Case | WQFN-16 |
Resolution | 16 bit |
Number of Channels | 2 Channel |
Sampling Rate | 700 kS/s |
Interface Type | SPI |
Architecture | SAR |
Reference Type | External, Internal |
Analog Supply Voltage | 4.5 V to 5.5 V |
Digital Supply Voltage | 1.65 V to 5.5 V |
SNR - Signal to Noise Ratio | 92 dB |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 125 C |
Packaging | Reel |
Features | Internal Reference |
Power Consumption | 45 mW |
Brand | Texas Instruments |
Moisture Sensitive | Yes |
Operating Supply Voltage | 4.5 V to 5.5 V |
Product Type | ADCs - Analog to Digital Converters |
SINAD - Signal to Noise and Distortion Ratio | 92.2 dB |
Factory Pack Quantity | 3000 |
Subcategory | Data Converter ICs |
For more information, please refer to datasheet
Documents
ADS54J69IRMP Datasheet |
More Information
The ADS54J69 is a low-power, wide-bandwidth, 16-bit, 500-MSPS, dual-channel, analog-to-digital converter (ADC). Designed for high signal-to-noise ratio (SNR), the device delivers a noise floor of –159 dBFS/Hz for applications aiming for highest dynamic range over a wide instantaneous bandwidth. The device supports the JESD204B serial interface with data rates up to 10.0 Gbps, supporting one or two lanes per ADC. The buffered analog input provides uniform input impedance across a wide frequency range and minimizes sample-and-hold glitch energy. Each ADC channel is directly connected to a wideband digital down-converter (DDC) block. The ADS54J69 provides excellent spurious-free dynamic range (SFDR) over a large input frequency range with very low power consumption.
