AMC1302DWVR Texas Instruments - Yeehing Electronics

±50-mV input, precision current sensing reinforced isolated amplifier

Pricing (USD)

Quantity	Unit Price
1 — 99	5.152
100 — 249	4.2
250 — 999	3.301
1,000 +	1.96

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Isolation Amplifiers
RoHS	Y
Series	AMC1302
Number of Channels	1 Channel
Isolation Voltage	5 kVrms
Isolation Type	Capacitive
GBP - Gain Bandwidth Product	280 kHz
CMRR - Common Mode Rejection Ratio	- 98 dB
Ib - Input Bias Current	- 28.5 uA
Vos - Input Offset Voltage	10 uV
Supply Voltage - Max	5.5 V
Supply Voltage - Min	3 V
Operating Supply Current	7.2 mA
Minimum Operating Temperature	- 55 C
Maximum Operating Temperature	+ 125 C
Mounting Style	SMD/SMT
Package / Case	SOIC-8
Packaging	Reel
Amplifier Type	Precision Amplifier
Product	Isolation Amplifiers
Brand	Texas Instruments
Shutdown	No Shutdown
Gain Error	0.03 %
Ios - Input Offset Current	10 nA
Moisture Sensitive	Yes
Pd - Power Dissipation	98.45 mW
Product Type	Isolation Amplifiers
PSRR - Power Supply Rejection Ratio	- 94 dB
Factory Pack Quantity	1000
Subcategory	Amplifier ICs
Vcm - Common Mode Voltage	1.44 V

For more information, please refer to datasheet

Documents

AMC1302DWVR Datasheet

More Information

The AMC1302 is a precision, isolated amplifier with an output separated from the input circuitry by an isolation barrier that is highly resistant to magnetic interference. This barrier is certified to provide reinforced galvanic isolation of up to 5 kVRMS according to VDE V 0884-11 and UL1577, and supports a working voltage of up to 1.5 kVRMS.
