Texas Instruments
AWR1243FBIGABLQ1
AWR1243FBIGABLQ1
Regular price
$10.54 USD
Regular price
Sale price
$10.54 USD
Unit price
per
Couldn't load pickup availability
AWR1243FBIGABLQ1 Texas Instruments - Yeehing Electronics
76-GHz to 81-GHz high-performance automotive MMIC
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 23.027 |
| 100 — 249 | 20.468 |
| 250 — 999 | 16.826 |
| 1,000 + | 10.54 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | RF Transceiver |
| RoHS | Y |
| Frequency Range | 76 GHz to 81 GHz |
| Maximum Data Rate | 600 Mb/s |
| Supply Voltage - Min | 1.14 V |
| Supply Voltage - Max | 1.32 V |
| Output Power | 12 dBm |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Interface Type | SPI |
| Package / Case | FCBGA-161 |
| Packaging | Tray |
| Operating Temperature Range | - 40 C to + 125 C |
| Series | AWR1243 |
| Brand | Texas Instruments |
| Mounting Style | SMD/SMT |
| Number of Receivers | 4 Receiver |
| Number of Transmitters | 3 Transmitter |
| Operating Supply Voltage | 1.2 V |
| Product Type | RF Transceiver |
| Factory Pack Quantity | 1 |
| Subcategory | Wireless & RF Integrated Circuits |
| Tradename | mmWave |
For more information, please refer to datasheet
Documents
| AWR1243FBIGABLQ1 Datasheet |
More Information
The AWR1243 device is an integrated single-chip FMCW transceiver capable of operation in the 76- to 81-GHz band. The device enables unprecedented levels of integration in an extremely small form factor. AWR1243 is an ideal solution for low power, self-monitored, ultra-accurate radar systems in the automotive space.
