Texas Instruments
BQ25050DQCT
BQ25050DQCT
Regular price
$0.47 USD
Regular price
Sale price
$0.47 USD
Unit price
per
Couldn't load pickup availability
BQ25050DQCT Texas Instruments - Yeehing Electronics
1-cell, 1-A, single input, Li-ion battery charger with 50-mA LDO
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.49 |
| 100 — 249 | 1.23 |
| 250 — 999 | 0.884 |
| 1,000 + | 0.47 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Battery Management |
| RoHS | Y |
| Product | Charge Management |
| Battery Type | Li-Ion |
| Output Voltage | 4.2 V |
| Output Current | 1 A |
| Operating Supply Voltage | 4.4 V to 30 V |
| Operating Supply Current | 3 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Package / Case | WSON-10 |
| Packaging | Reel |
| Series | BQ25050 |
| Brand | Texas Instruments |
| Mounting Style | SMD/SMT |
| Moisture Sensitive | Yes |
| Pd - Power Dissipation | 1.7 W |
| Product Type | Battery Management |
| Factory Pack Quantity | 250 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.000526 oz |
For more information, please refer to datasheet
Documents
| BQ25050DQCT Datasheet |
More Information
The bq25050 is a highly integrated Li-Ion linear battery charger targeted at space-limited portable applications. It operates from either a USB port or AC Adapter and charges a single-cell Li-Ion battery with up to 1A of charge current. The 30V input voltage range with input over-voltage protections supports low-cost unregulated adapters.
