Texas Instruments
BQ500101DPCR
BQ500101DPCR
Regular price
$0.41 USD
Regular price
Sale price
$0.41 USD
Unit price
per
Couldn't load pickup availability
BQ500101DPCR Texas Instruments - Yeehing Electronics
NexFET Power Stage
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.319 |
| 100 — 249 | 1.09 |
| 250 — 999 | 0.783 |
| 1,000 + | 0.41 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Minimum Operating Temperature | -40 |
| Maximum Operating Temperature | 125 |
| Factory Pack Quantity | 2,500 |
| Package | Pins | VSON-CLIP (DPC) | 8 |
For more information, please refer to datasheet
Documents
| BQ500101DPCR Datasheet |
More Information
The bq500101 NexFET Power Stage is optimized for wireless power applications covering the WPC v1.2 medium power specification. The device can be used for both the rail voltage control in fixed frequency transmitter types as well as the coil drivers for both fixed and variable frequency types. This combination produces a high-current, high-efficiency, and high-speed switching device in a small 3.5 × 4.5 mm outline package. In addition, the PCB footprint is optimized to help reduce design time and simplify the completion of the overall system design.
