CC430F6127IRGCR Texas Instruments - Yeehing Electronics

20 MHz MCU with 32KB Flash, 4KB SRAM, Sub-1 GHz radio, AES-128, I2C/SPI/UART, 96 seg LCD

Pricing (USD)

Quantity	Unit Price
1 — 99	3.698
100 — 249	3.015
250 — 999	2.37
1,000 +	1.15

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	RF Microcontrollers - MCU
RoHS	Y
Core	MSP430
Operating Frequency	300 MHz to 928 MHz
Data Bus Width	16 bit
Program Memory Size	32 kB
Maximum Operating Temperature	+ 85 C
Package / Case	VQFN-64
Mounting Style	SMD/SMT
Packaging	Reel
Series	CC430F6127
Brand	Texas Instruments
Minimum Operating Temperature	- 40 C
Moisture Sensitive	Yes
Processor Series	CC430 RF
Product Type	RF Microcontrollers - MCU
Factory Pack Quantity	2000
Subcategory	Wireless & RF Integrated Circuits
Unit Weight	0.008021 oz

For more information, please refer to datasheet

Documents

CC430F6127IRGCR Datasheet

More Information

The TI CC430 family of ultra-low-power system-on-chip (SoC) microcontrollers with integrated RF transceiver cores consists of several devices that feature different sets of peripherals targeted for a wide range of applications. The architecture, combined with five low-power modes, is optimized to achieve extended battery life in portable measurement applications. The devices feature the powerful MSP430 16‑bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency.
