CSD17309Q3 Texas Instruments - Yeehing Electronics
30-V, N channel NexFET™ power MOSFET, single SON 3 mm x 3 mm, 6.3 mOhm
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.805 |
| 100 — 249 | 0.619 |
| 250 — 999 | 0.456 |
| 1,000 + | 0.23 |
The above prices are for reference only.
Specifications
| Manufacturer | Vishay |
| Product Category | MOSFET |
| RoHS | E |
| Technology | Si |
| Mounting Style | SMD/SMT |
| Package / Case | SO-8 |
| Number of Channels | 2 Channel |
| Transistor Polarity | N-Channel |
| Vds - Drain-Source Breakdown Voltage | 20 V |
| Id - Continuous Drain Current | 8 A |
| Rds On - Drain-Source Resistance | 18 mOhms |
| Vgs th - Gate-Source Threshold Voltage | 600 mV |
| Vgs - Gate-Source Voltage | 4.5 V |
| Qg - Gate Charge | 22 nC |
| Minimum Operating Temperature | - 55 C |
| Maximum Operating Temperature | + 150 C |
| Pd - Power Dissipation | 3.1 W |
| Configuration | Dual |
| Channel Mode | Enhancement |
| Tradename | TrenchFET |
| Packaging | Reel |
| Height | 1.75 mm |
| Length | 4.9 mm |
| Series | SI9 |
| Transistor Type | 2 N-Channel |
| Width | 3.9 mm |
| Brand | Vishay / Siliconix |
| Forward Transconductance - Min | 45 S |
| Fall Time | 12 ns |
| Product Type | MOSFET |
| Rise Time | 10 ns |
| Factory Pack Quantity | 2500 |
| Subcategory | MOSFETs |
| Typical Turn-Off Delay Time | 35 ns |
| Typical Turn-On Delay Time | 15 ns |
| Part # Aliases | SI9926CDY-E3 |
| Unit Weight | 0.006596 oz |
For more information, please refer to datasheet
Documents
| CSD17309Q3 Datasheet |
More Information
This 30 V, 4.2 mΩ NexFET™ power MOSFET is designed to minimize losses in power conversion applications and optimized for 5 V gate drive applications.
