CSD95490Q5MC Texas Instruments - Yeehing Electronics
75A Synchronous Buck NexFET™ Smart Power Stage with DualCool Package
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 4.008 |
100 — 249 | 3.267 |
250 — 999 | 2.568 |
1,000 + | 1.52 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Controllers |
RoHS | Y |
Topology | Buck |
Number of Outputs | 1 Output |
Switching Frequency | 1.25 MHz |
Duty Cycle - Max | 85 % |
Output Voltage | 5.5 V |
Output Current | 75 A |
Minimum Operating Temperature | - 55 C |
Maximum Operating Temperature | + 150 C |
Mounting Style | SMD/SMT |
Package / Case | VSON-CLIP-12 |
Packaging | Reel |
Isolation | Non-Isolated |
Operating Temperature Range | - 55 C to + 150 C |
Product | Synchronous Buck Converter |
Series | CSD95490Q5MC |
Brand | Texas Instruments |
Shutdown | Shutdown |
Moisture Sensitive | Yes |
Operating Supply Voltage | 4.5 V to 16 V |
Product Type | Switching Controllers |
Factory Pack Quantity | 2500 |
Subcategory | PMIC - Power Management ICs |
Tradename | NexFET |
Unit Weight | 0.004579 oz |
For more information, please refer to datasheet
Documents
CSD95490Q5MC Datasheet |
More Information
The CSD95490Q5MC NexFET™ power stage is a highly optimized design for use in a high-power, high-density synchronous buck converter. This product integrates the driver IC and power MOSFETs to complete the power stage switching function. This combination produces high-current, high-efficiency, and high-speed switching capability in a small 5-mm × 6-mm outline package. It also integrates the accurate current sensing and temperature sensing functionality to simplify system design and improve accuracy. In addition, the PCB footprint has been optimized to help reduce design time and simplify the completion of the overall system design.
