Texas Instruments
DIX4192IPFBRQ1
DIX4192IPFBRQ1
Regular price
$3.66 USD
Regular price
Sale price
$3.66 USD
Unit price
per
Couldn't load pickup availability
DIX4192IPFBRQ1 Texas Instruments - Yeehing Electronics
Automotive Integrated Digital Audio Interface Receiver and Transmitter
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 8.42 |
| 100 — 249 | 6.864 |
| 250 — 999 | 5.395 |
| 1,000 + | 3.66 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Audio Transmitters, Receivers, Transceivers |
| RoHS | Y |
| Series | DIX4192-Q1 |
| Type | Integrated Digital Audio Interface Receiver and Transmitter |
| Number of Channels | 2 Channel |
| Interface Type | I2C/SPI |
| Operating Supply Voltage | 1.8 V, 3.3 V |
| Operating Supply Current | 6.7 mA, 15 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 105 C |
| Mounting Style | SMD/SMT |
| Package / Case | TQFP-48 |
| Qualification | AEC-Q100 |
| Packaging | Reel |
| Product | Audio Line Drivers / Receivers |
| Sampling Rate | 192 kS/s |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Number of Drivers | 1 Driver |
| Number of Receivers | 4 Receiver |
| Pd - Power Dissipation | 242 mW |
| Product Type | Audio Transmitters, Receivers, Transceivers |
| Factory Pack Quantity | 1000 |
| Subcategory | Audio ICs |
| Supply Voltage - Max | 3.6 V |
| Supply Voltage - Min | 1.65 V |
| Unit Weight | 0.004794 oz |
For more information, please refer to datasheet
Documents
| DIX4192IPFBRQ1 Datasheet |
More Information
The DIX4192-Q1 device is a highly-integrated CMOS device designed for use in professional and broadcast digital audio systems. The DIX4192-Q1 combines a digital audio interface receiver (DIR) and transmitter (DIT), two audio serial ports, and flexible distribution logic for interconnection of the function block data and clocks.
