DRV3220QPHPRQ1 Texas Instruments - Yeehing Electronics
Automotive 12-V & 24-V battery 3-phase gate driver with enhanced protection
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 7.124 |
| 100 — 249 | 5.808 |
| 250 — 999 | 4.565 |
| 1,000 + | 2.71 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Motor / Motion / Ignition Controllers & Drivers |
| RoHS | Y |
| Product | Brushed DC Motor Drivers |
| Type | 3 Phase |
| Output Current | 1 A |
| Operating Supply Current | 22 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | SMD/SMT |
| Package / Case | HTQFP-48 |
| Packaging | Reel |
| Features | SPI/I2C, Watchdog Timer, SafeTI |
| Number of Outputs | 1 Output |
| Operating Temperature Range | - 40 C to + 125 C |
| Series | DRV3220-Q1 |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Product Type | Motor / Motion / Ignition Controllers & Drivers |
| Rds On - Drain-Source Resistance | 2 Ohms |
| Factory Pack Quantity | 1000 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.008935 oz |
For more information, please refer to datasheet
Documents
| DRV3220QPHPRQ1 Datasheet |
More Information
The DRV3220-Q1 bridge driver is dedicated to automotive three-phase brushless DC motor control applications. The device provides six dedicated drivers for standard-level N-channel MOSFET transistors. A boost converter with an integrated FET provides the overdrive voltage, allowing full control on the power stages even for low battery voltage down to 4.75 V. The strong driver strength is suitable for high-current applications and programmable to limit peak output current.
