DRV8304HRHAT Texas Instruments - Yeehing Electronics
40-V max 3-phase smart gate driver with current shunt amplifier
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.933 |
| 100 — 249 | 2.57 |
| 250 — 999 | 1.802 |
| 1,000 + | 1.02 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Motor / Motion / Ignition Controllers & Drivers |
| RoHS | Y |
| Product | Brushless DC Motor Controllers |
| Type | Half Bridge |
| Operating Supply Voltage | 6 V to 38 V |
| Output Current | 300 mA |
| Operating Supply Current | 5 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | SMD/SMT |
| Package / Case | VQFN-40 |
| Packaging | Reel |
| Features | Current Sense Amplifier, Hardware Management I/F, Smart Gate Drive |
| Number of Outputs | 3 Output |
| Operating Frequency | 200 kHz |
| Operating Temperature Range | - 40 C to + 125 C |
| Output Voltage | 10 V |
| Series | DRV8304 |
| Brand | Texas Instruments |
| Development Kit | BOOSTXL-DRV8304H |
| Moisture Sensitive | Yes |
| Product Type | Motor / Motion / Ignition Controllers & Drivers |
| Factory Pack Quantity | 250 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.004187 oz |
For more information, please refer to datasheet
Documents
| DRV8304HRHAT Datasheet |
More Information
The DRV8304 device is an integrated gate driver for 3-phase brushless DC (BLDC) motors applications for 12-V and 24-V DC rails. These applications include field-oriented control (FOC), sinusoidal current control, and trapezoidal current control of BLDC motors. The device integrates three current-sense amplifiers (CSA) for sensing the phase currents of BLDC motors for optimum FOC and current-control system implementation. An AUTOCAL feature automatically calibrates the CSA offset error for accurate current sensing.
