DRV8701PRGET Texas Instruments - Yeehing Electronics
47-V H-bridge smart gate driver
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.175 |
| 100 — 249 | 1.796 |
| 250 — 999 | 1.29 |
| 1,000 + | 0.68 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Motor / Motion / Ignition Controllers & Drivers |
| RoHS | Y |
| Product | Brushed DC Motor Drivers |
| Type | Half Bridge |
| Operating Supply Voltage | 5.9 V to 45 V |
| Output Current | 6 mA to 150 mA |
| Operating Supply Current | 6 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | SMD/SMT |
| Package / Case | VQFN-24 |
| Packaging | Reel |
| Features | Smart Gate Drive, Current Sense Amplifier, Current Regulation, Single H-bridge |
| Height | 1 mm |
| Length | 4.15 mm |
| Number of Outputs | 1 Output |
| Operating Temperature Range | - 40 C to + 125 C |
| Output Voltage | 9.5 V |
| Series | DRV8701 |
| Width | 4.15 mm |
| Brand | Texas Instruments |
| Load Voltage Rating | 3.3 V, 4.8 V |
| Development Kit | DRV8701EVM |
| Moisture Sensitive | Yes |
| Product Type | Motor / Motion / Ignition Controllers & Drivers |
| Factory Pack Quantity | 250 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.001926 oz |
For more information, please refer to datasheet
Documents
| DRV8701PRGET Datasheet |
More Information
The DRV8701 is a single H-bridge gate driver that uses four external N-channel MOSFETs targeted to drive a 12-V to 24-V bidirectional brushed DC motor.
