DRV8843PWPR Texas Instruments - Yeehing Electronics

45-V, 2.5-A bipolar stepper or dual H-bridge motor driver with current regulation and PWM control

Pricing (USD)

Quantity	Unit Price
1 — 99	3.466
100 — 249	3.037
250 — 999	2.13
1,000 +	1.20

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Motor / Motion / Ignition Controllers & Drivers
RoHS	Y
Product	Stepper Motor Controllers / Drivers
Type	Bridge Driver
Operating Supply Voltage	8.2 V to 45 V
Output Current	1.75 A
Operating Supply Current	5 mA
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	HTSSOP-28
Packaging	Reel
Features	Current Regulation
Number of Outputs	2 Output
Operating Temperature Range	- 40 C to + 85 C
Series	DRV8843
Brand	Texas Instruments
Development Kit	DRV8843EVM
Moisture Sensitive	Yes
Product Type	Motor / Motion / Ignition Controllers & Drivers
Rds On - Drain-Source Resistance	400 mOhms
Factory Pack Quantity	2000
Subcategory	PMIC - Power Management ICs
Unit Weight	0.004233 oz

For more information, please refer to datasheet

Documents

DRV8843PWPR Datasheet

More Information

The DRV8843 provides an integrated dual H-bridge motor driver solution for printers, scanners, and other automated equipment applications. The device can be used to drive one or two brushed DC motors, a bipolar stepper motor, or other loads. A simple PWM interface allows easy interfacing to controller circuits.
