DS90CR482VSX/NOPB


YeeHing #: Y007-DS90CR482VSX/NOPB
Inventory: 4400

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

DS90CR482VSX/NOPB Texas Instruments - Yeehing Electronics

48-Bit LVDS Channel Link Deserializer - 65 - 112 MHz

Pricing (USD)

Quantity Unit Price
1 — 99 11.57
100 — 249 10.107
250 — 999 7.792
1,000 + 4.88

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category LVDS Interface IC
RoHS Y
Type CMOS, TTL
Number of Drivers 48 Driver
Number of Receivers 8 Receiver
Data Rate 672 Mb/s
Input Type LVDS
Output Type LVCMOS
Supply Voltage - Max 3.6 V
Supply Voltage - Min 3 V
Minimum Operating Temperature - 10 C
Maximum Operating Temperature + 70 C
Mounting Style SMD/SMT
Package / Case TQFP-100
Packaging Reel
Height 1 mm
Input Voltage MAX 100 mV
Length 14 mm
Series DS90CR482
Width 14 mm
Brand Texas Instruments
Input Voltage MIN - 100 mV
Moisture Sensitive Yes
Operating Supply Voltage 3.3 V
Pd - Power Dissipation 2.3 W
Product Type LVDS Interface IC
Factory Pack Quantity 1000
Subcategory Interface ICs
Unit Weight 0.023175 oz

For more information, please refer to datasheet

Documents

DS90CR482VSX/NOPB Datasheet

More Information

The DS90CR481 transmitter converts 48 bits of CMOS/TTL data into eight LVDS (Low Voltage Differential Signaling) data streams. A phase-locked transmit clock is transmitted in parallel with the data streams over a ninth LVDS link. Every cycle of the transmit clock 48 bits of input data are sampled and transmitted. The DS90CR482 receiver converts the LVDS data streams back into 48 bits of LVCMOS/TTL data. At a transmit clock frequency of 112MHz, 48 bits of TTL data are transmitted at a rate of 672Mbps per LVDS data channel. Using a 112MHz clock, the data throughput is 5.38Gbit/s (672Mbytes/s). At a transmit clock frequency of 112MHz, 48 bits of TTL data are transmitted at a rate of 672Mbps per LVDS data channel. Using a 66MHz clock, the data throughput is 3.168Gbit/s (396Mbytes/s).
