DS92001TLD/NOPB Texas Instruments - Yeehing Electronics

3.3-V B/LVDS-BLVDS buffer

Pricing (USD)

Quantity	Unit Price
1 — 99	2.365
100 — 249	1.954
250 — 999	1.403
1,000 +	0.74

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	LVDS Interface IC
RoHS	Y
Type	LVDS, BLVDS
Number of Drivers	1 Driver
Number of Receivers	1 Receiver
Data Rate	400 Mb/s
Input Type	CML, LVDS, LVPECL
Output Type	LVDS
Supply Voltage - Max	3.6 V
Supply Voltage - Min	3 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	LLP-8
Packaging	Reel
Height	0.8 mm
Input Voltage MAX	- 5 mV
Length	3 mm
Series	DS92001
Width	3 mm
Brand	Texas Instruments
Input Voltage MIN	- 70 mV
Maximum Output Voltage	500 mV
Moisture Sensitive	Yes
Operating Supply Current	65 mA
Operating Supply Voltage	3.3 V
Pd - Power Dissipation	726 mW
Product Type	LVDS Interface IC
Propagation Delay Time	2 ns
Factory Pack Quantity	1000
Subcategory	Interface ICs
Unit Weight	0.000952 oz

For more information, please refer to datasheet

Documents

DS92001TLD/NOPB Datasheet
