INA215BIRSWR


YeeHing #: Y001-INA215BIRSWR
Inventory: 4800

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

INA215BIRSWR Texas Instruments - Yeehing Electronics

26V, bi-directional, high-precision current sense amplifier

Pricing (USD)

Quantity Unit Price
1 — 99 0.618
100 — 249 0.475
250 — 999 0.35
1,000 + 0.17

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Current Sense Amplifiers
RoHS Y
Series INA215
Number of Channels 1 Channel
GBP - Gain Bandwidth Product 40 kHz
Vcm - Common Mode Voltage - 300 mV to 26 V
CMRR - Common Mode Rejection Ratio 105 dB
Ib - Input Bias Current 35 uA
Vos - Input Offset Voltage 1 uV
Supply Voltage - Max 26 V
Supply Voltage - Min 2.7 V
Operating Supply Current 65 uA
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 125 C
Mounting Style SMD/SMT
Package / Case UQFN-10
Packaging Reel
Accuracy 1 %
Amplifier Type Current Sense
Product Current Sense Amplifiers
Brand Texas Instruments
Shutdown Shutdown
Topology Current Shunt Feedback
Development Kit INA210-215EVM
en - Input Voltage Noise Density 25 nV/sqrt Hz
Gain Error 0.02 %
Gain V/V 75 V/V
Ios - Input Offset Current 20 nA
Product Type Current Sense Amplifiers
SR - Slew Rate 400 mV/us
Factory Pack Quantity 3000
Subcategory Amplifier ICs
Unit Weight 0.000092 oz

For more information, please refer to datasheet

Documents

INA215BIRSWR Datasheet

More Information

The INA21x are voltage-output, current-shunt monitors (also called current-sense amplifiers) that are commonly used for overcurrent protection, precision-current measurement for system optimization, or in closed-loop feedback circuits. This series of devices can sense drops across shunts at common-mode voltages from –0.3 V to 26 V, independent of the supply voltage. Six fixed gains are available: 50 V/V, 75 V/V, 100 V/V, 200 V/V, 500 V/V, or 1000 V/V. The low offset of the zero-drift architecture enables current sensing with maximum drops across the shunt as low as 10-mV full-scale.
