LM2574HVMX-12/NOPB


YeeHing #: Y012-LM2574HVMX-12/NOPB
Inventory: 7600

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

LM2574HVMX-12/NOPB Texas Instruments - Yeehing Electronics

SIMPLE SWITCHER 0.5A Step-Down Voltage Regulator

Pricing (USD)

Quantity Unit Price
1 — 99 3.222
100 — 249 2.823
250 — 999 1.979
1,000 + 1.28

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Switching Voltage Regulators
RoHS Y
Mounting Style SMD/SMT
Package / Case SOIC-Wide-14
Output Voltage 12 V
Output Current 500 mA
Number of Outputs 1 Output
Input Voltage MAX 60 V
Topology Buck, Inverting
Input Voltage MIN 4 V
Switching Frequency 58 kHz
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 125 C
Series LM2574HV
Packaging Reel
Operating Temperature Range - 40 C to + 125 C
Type Inverting, Step Down
Brand Texas Instruments
Moisture Sensitive Yes
Operating Supply Current 5 mA
Product Type Switching Voltage Regulators
Factory Pack Quantity 1000
Subcategory PMIC - Power Management ICs
Tradename SIMPLE SWITCHER
Unit Weight 0.013140 oz

For more information, please refer to datasheet

Documents

LM2574HVMX-12/NOPB Datasheet

More Information

The LM2574xx series of regulators are monolithic integrated circuits that provide all the active functions for a step-down (buck) switching regulator, capable of driving a 0.5-A load with excellent line and load regulation. These devices are available in fixed output voltages of 3.3 V, 5 V, 12 V, 15 V, and an adjustable output version.
