LM2750LD-ADJ/NOPB Texas Instruments - Yeehing Electronics

2.7-V to 5.6-VIN low-noise switched-capacitor boost doubler

Pricing (USD)

Quantity	Unit Price
1 — 99	1.431
100 — 249	1.182
250 — 999	0.849
1,000 +	0.45

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Switching Voltage Regulators
RoHS	Y
Mounting Style	SMD/SMT
Package / Case	WSON-10
Output Voltage	3.8 V to 5.2 V
Output Current	120 mA
Number of Outputs	1 Output
Input Voltage MAX	5.9 V
Topology	Boost
Input Voltage MIN	2.7 V
Switching Frequency	1700 kHz
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Series	LM2750
Packaging	Reel
Height	0.8 mm
Input Voltage	2.7 V to 5.6 V
Length	3 mm
Operating Temperature Range	- 40 C to + 85 C
Product	Voltage Regulators
Type	Step Up
Width	3 mm
Brand	Texas Instruments
Shutdown	Shutdown
Moisture Sensitive	Yes
Operating Supply Current	5 mA
Product Type	Switching Voltage Regulators
Factory Pack Quantity	1000
Subcategory	PMIC - Power Management ICs
Supply Voltage - Min	2.7 V
Unit Weight	0.000698 oz

For more information, please refer to datasheet

Documents

LM2750LD-ADJ/NOPB Datasheet

More Information

The LM2750 is a regulated switched-capacitor doubler that produces a low-noise output voltage. The 5-V output voltage option (LM2750-5.0) can supply up to 120 mA of output current over a 2.9-V to 5.6-V input range, as well as up to 40 mA of output current when the input voltage is as low as 2.7 V. An adjustable output voltage option with similar output current capabilities is also available (LM2750-ADJ). The LM2750 has been placed in TI's 10-pin WSON, a package with excellent thermal properties that keeps the part from overheating under almost all rated operating conditions.
