LM2936DT-3.3/NOPB


YeeHing #: Y012-LM2936DT-3.3/NOPB
Inventory: 7800

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

LM2936DT-3.3/NOPB Texas Instruments - Yeehing Electronics

50-mA, 60-V, low-IQ, low-dropout voltage regulator with reverse voltage protection

Pricing (USD)

Quantity Unit Price
1 — 99 2.159
100 — 249 1.783
250 — 999 1.281
1,000 + 0.67

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category LDO Voltage Regulators
RoHS Y
Mounting Style SMD/SMT
Package / Case TO-252-3
Output Voltage 3.3 V
Output Current 50 mA
Number of Outputs 1 Output
Polarity Positive
Quiescent Current 20 uA
Input Voltage MAX 40 V
Input Voltage MIN 4 V
Output Type Fixed
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 125 C
Dropout Voltage 200 mV
Series LM2936
Packaging Tube
Operating Temperature Range - 40 C to + 125 C
Product Ultra Low Quiescent Current LDO Voltage Regulators
Tolerance 2 %
Type Ultra Low Quiescent Current
Brand Texas Instruments
Dropout Voltage - Max 0.1 V at 100 uA, 0.4 V at 50 mA
PSRR / Ripple Rejection - Typ - 60 dB
Voltage Regulation Accuracy +/- 2 %
Ib - Input Bias Current 15 uA
Line Regulation 30 mV
Load Regulation 30 mV
Moisture Sensitive Yes
Operating Supply Current 15 uA
Product Type LDO Voltage Regulators
Factory Pack Quantity 75
Subcategory PMIC - Power Management ICs
Unit Weight 0.139332 oz

For more information, please refer to datasheet

Documents

LM2936DT-3.3/NOPB Datasheet

More Information

The LM2936 ultra-low quiescent current regulator features low dropout voltage and low current in the standby mode. With less than 15-μA quiescent current at a 100-μA load, the LM2936 is ideally suited for automotive and other battery operated systems. The LM2936 retains all of the features that are common to low dropout regulators including a low dropout PNP pass device, short circuit protection, reverse battery protection, and thermal shutdown. The LM2936 has a 40-V maximum operating voltage limit, a −40°C to 125°C operating temperature range, and ±3% output voltage tolerance over the entire output current, input voltage, and temperature range. The LM2936 is available in a TO-92 through-hole package, as well as SOIC-8, VSSOP, SOT–223, and TO-252 surface mount packages.
