LM338T/NOPB Texas Instruments - Yeehing Electronics
5-A, 40-V, low-IQ, adjustable linear voltage regulator
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 1.756 |
100 — 249 | 1.45 |
250 — 999 | 1.042 |
1,000 + | 0.55 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Linear Voltage Regulators |
RoHS | Y |
Mounting Style | Through Hole |
Package / Case | TO-220-3 |
Number of Outputs | 1 Output |
Polarity | Positive |
Output Voltage | 1.2 V to 32 V |
Output Current | 5 A |
Output Type | Adjustable |
Input Voltage MAX | 40 V |
Input Voltage MIN | 4.2 V |
Minimum Operating Temperature | 0 C |
Maximum Operating Temperature | + 125 C |
Load Regulation | 0.5 % |
Line Regulation | 0.03 %/V |
Series | LM338 |
Packaging | Tube |
Operating Temperature Range | 0 C to + 125 C |
Brand | Texas Instruments |
PSRR / Ripple Rejection - Typ | 75 dB |
Pd - Power Dissipation | 25 W |
Product Type | Linear Voltage Regulators |
Factory Pack Quantity | 45 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.074075 oz |
For more information, please refer to datasheet
Documents
LM338T/NOPB Datasheet |
More Information
The LM138 series of adjustable 3-terminal positive voltage regulators is capable of supplying in excess of 5 A over a 1.2-V to 32-V output range. They are exceptionally easy to use and require only 2 resistors to set the output voltage. Careful circuit design has resulted in outstanding load and line regulation, comparable to many commercial power supplies. The LM138 family is supplied in a standard 3-lead transistor package.
