LM3466MR/NOPB Texas Instruments - Yeehing Electronics

Multi-String LED current balancer for use with constant current power Supplies

Pricing (USD)

Quantity	Unit Price
1 — 99	1.344
100 — 249	1.11
250 — 999	0.797
1,000 +	0.42

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	LED Lighting Drivers
RoHS	Y
Number of Channels	1 Channel
Output Current	1.5 A
Input Voltage	6 V to 70 V
Supply Current - Max	640 uA
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 125 C
Mounting Style	SMD/SMT
Package / Case	SO-PowerPad-8
Series	LM3466
Packaging	Tube
Features	Integrated Switch, Thermal Shutdown
Operating Temperature Range	- 40 C to + 125 C
Output Type	Current Mode
Type	Linear
Brand	Texas Instruments
Topology	Boost
Dimming	Analog
Moisture Sensitive	Yes
Product Type	LED Lighting Drivers
Factory Pack Quantity	95
Subcategory	Driver ICs
Unit Weight	0.002490 oz

For more information, please refer to datasheet

Documents

LM3466MR/NOPB Datasheet

More Information
