Texas Instruments
LM4952TS/NOPB
LM4952TS/NOPB
Regular price
$0.92 USD
Regular price
Sale price
$0.92 USD
Unit price
per
Couldn't load pickup availability
LM4952TS/NOPB Texas Instruments - Yeehing Electronics
3.1-W, stereo, 9.6- to 16-V, analog input Class-AB audio amplifier
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.654 |
| 100 — 249 | 2.326 |
| 250 — 999 | 1.631 |
| 1,000 + | 0.92 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Audio Amplifiers |
| RoHS | E |
| Series | LM4952 |
| Product | Audio Amplifiers |
| Output Power | 3.8 W |
| Mounting Style | SMD/SMT |
| Package / Case | TO-263-9 |
| Audio - Load Impedance | 4 Ohms |
| THD plus Noise | 0.08 % |
| Supply Voltage - Max | 16 V |
| Supply Voltage - Min | 9.6 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Tube |
| Height | 4.57 mm |
| Input Type | Analog |
| Length | 10.16 mm |
| Width | 8.69 mm |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Operating Supply Current | 18 mA |
| Operating Supply Voltage | 16 V |
| Product Type | Audio Amplifiers |
| PSRR - Power Supply Rejection Ratio | 89 dB |
| Factory Pack Quantity | 45 |
| Subcategory | Audio ICs |
| Unit Weight | 0.050043 oz |
For more information, please refer to datasheet
Documents
| LM4952TS/NOPB Datasheet |
More Information
The LM4952 is a dual audio power amplifier primarily designed for demanding applications in flat panel monitors and TV's. It is capable of delivering 3.1 watts per channel to a 4Ω single-ended load with less than 1% THD+N when powered by a 12VDC power supply.
