LM5145RGYR Texas Instruments - Yeehing Electronics
75V Synchronous Buck Controller With Wide Input Voltage and Duty Cycle Ranges
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 3.268 |
100 — 249 | 2.864 |
250 — 999 | 2.008 |
1,000 + | 3.22 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Controllers |
RoHS | Y |
Topology | Buck |
Number of Outputs | 1 Output |
Switching Frequency | 100 kHz to 1 MHz |
Duty Cycle - Max | 99 % |
Input Voltage | 6 V to 75 V |
Output Voltage | 0.8 V to 60 V |
Output Current | 30 A |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 125 C |
Mounting Style | SMD/SMT |
Package / Case | VQFN-20 |
Packaging | Reel |
Description/Function | Synchronous buck DC-DC controller |
Operating Temperature Range | - 40 C to + 125 C |
Product | DC-DC Controllers |
Series | LM5145 |
Brand | Texas Instruments |
Shutdown | Shutdown |
Development Kit | LM5145EVM-HD-20A |
Fall Time | 4 ns |
Moisture Sensitive | Yes |
Operating Supply Current | 1.8 mA |
Operating Supply Voltage | 6 V to 75 V |
Product Type | Switching Controllers |
Rise Time | 7 ns |
Factory Pack Quantity | 3000 |
Subcategory | PMIC - Power Management ICs |
For more information, please refer to datasheet
Documents
LM5145RGYR Datasheet |
More Information
The LM5145 75-V synchronous buck controller regulates from a high input voltage source or from an input rail subject to high voltage transients, minimizing the need for external surge suppression components. A high-side switch minimum on-time of 40 ns gives large step-down ratios, enabling the direct step-down conversion from a 48-V nominal input to low-voltage rails for reduced system complexity and solution cost. The LM5145 continues to operate during input voltage dips as low as 6 V, at nearly 100% duty cycle if needed, making it an excellent choice for high-performance industrial control, robotic, datacom, and RF power applications.
