LM555J/883 Texas Instruments - Yeehing Electronics

Timer

Pricing (USD)

Quantity	Unit Price
1 — 99	21.039
100 — 249	18.377
250 — 999	14.17
1,000 +	8.87

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Minimum Operating Temperature	-55
Maximum Operating Temperature	125
Factory Pack Quantity	40
Package | Pins	CDIP (NAB) | 8

For more information, please refer to datasheet

Documents

LM555J/883 Datasheet

More Information

The LM555 is a highly stable device for generating accurate time delays or oscillation. Additional terminals are provided for triggering or resetting if desired. In the time delay mode of operation, the time is precisely controlled by one external resistor and capacitor. For astable operation as an oscillator, the free running frequency and duty cycle are accurately controlled with two external resistors and one capacitor. The circuit may be triggered and reset on falling waveforms, and the output circuit can source or sink up to 200mA or drive TTL circuits.
