Texas Instruments
LM78L09ITPX/NOPB
LM78L09ITPX/NOPB
Couldn't load pickup availability
LM78L09ITPX/NOPB Texas Instruments - Yeehing Electronics
100-mA, 30-V, linear voltage regulator
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.887 |
| 100 — 249 | 0.682 |
| 250 — 999 | 0.502 |
| 1,000 + | 0.25 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Minimum Operating Temperature | -40 |
| Maximum Operating Temperature | 85 |
| Factory Pack Quantity | 3,000 |
| Package | Pins | DSBGA (YPB) | 8 |
For more information, please refer to datasheet
Documents
| LM78L09ITPX/NOPB Datasheet |
More Information
The LM78L series (LM78Lxx throughout this document) of three terminal positive regulators is available with several fixed output voltages, making them useful in a wide range of applications. Used as a Zener-diode and resistor combination replacement, the LM78Lxx usually provides an effective output impedance improvement of two orders of magnitude and lower quiescent current. These regulators can provide local, on-card regulation, eliminating distribution problems associated with single-point regulation. The available voltages allow the LM78Lxx to be used in logic systems, instrumentation, HiFi, and other solid-state electronic equipment.
