Description
LM8335TLE/NOPB Texas Instruments - Yeehing Electronics
General-Purpose Output Expander with MIPI RFFE Host Interface
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.195 |
| 100 — 249 | 1.813 |
| 250 — 999 | 1.302 |
| 1,000 + | 0.69 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Interface - I/O Expanders |
| RoHS | Y |
| Number of I/Os | 8 I/O |
| Maximum Clock Frequency | 26 MHz |
| Operating Supply Voltage | 1.8 V to 3.3 V |
| Minimum Operating Temperature | - 30 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | DSBGA-16 |
| Packaging | Reel |
| Features | Low Voltage, Open-Drain I/O Type |
| Product | I/O Expanders |
| Series | LM8335 |
| Type | I/O Expander |
| Brand | Texas Instruments |
| Development Kit | LM8335EVM |
| Operating Supply Current | 400 uA |
| Product Type | I/O Expanders |
| Factory Pack Quantity | 250 |
| Subcategory | Interface ICs |
For more information, please refer to datasheet
Documents
| LM8335TLE/NOPB Datasheet |
More Information
The LM8335 General Purpose Output Expander is a dedicated device to provide flexible and general purpose, host programmable output expansion functions. This device communicates with a host processor through a MIPI® RFFE Interface (Mobile Industry Processor Interface RF Front-End).
