LMD18200-2D/883 Texas Instruments - Yeehing Electronics

2.4A, 55V H-Bridge

Pricing (USD)

Quantity	Unit Price
1 — 99	195.653
100 — 249	177.099
250 — 999	172.039
1,000 +	118.07

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Minimum Operating Temperature	-55
Maximum Operating Temperature	125
Factory Pack Quantity	15
Package | Pins	CDIP SB (NAZ) | 24

For more information, please refer to datasheet

Documents

LMD18200-2D/883 Datasheet

More Information

The LMD18200 is a 2.4A H-Bridge designed for motion control applications. The device is built using a multi-technology process which combines bipolar and CMOS control circuitry with DMOS power devices on the same monolithic structure. Ideal for driving DC and stepper motors; the LMD18200 accommodates peak output currents up to 6A. An innovative circuit which facilitates low-loss sensing of the output current has been implemented.
