80V GaN Half Bridge Power Stage
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 9.495 |
| 100 — 249 | 8.294 |
| 250 — 999 | 6.395 |
| 1,000 + | 4.58 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Gate Drivers |
| RoHS | Y |
| Product | Half-Bridge Drivers |
| Type | High Side, Low Side |
| Mounting Style | SMD/SMT |
| Package / Case | QFM-9 |
| Number of Drivers | 1 Driver |
| Number of Outputs | 1 Output |
| Output Current | 10 A |
| Configuration | Single |
| Supply Voltage - Min | 4.75 V |
| Supply Voltage - Max | 5.25 V |
| Operating Supply Current | 3 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Series | LMG5200 |
| Packaging | Reel |
| Operating Temperature Range | - 40 C to + 125 C |
| Technology | Si |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Product Type | Gate Drivers |
| Rds On - Drain-Source Resistance | 15 Ohms |
| Factory Pack Quantity | 2000 |
| Subcategory | PMIC - Power Management ICs |
For more information, please refer to datasheet
Documents
| LMG5200MOFR Datasheet |
More Information
The LMG5200 device, an 80-V, 10-A driver plus GaN half-bridge power stage, provides an integrated power stage solution using enhancement-mode Gallium Nitride (GaN) FETs. The device consists of two 80-V GaN FETs driven by one high-frequency GaN FET driver in a half-bridge configuration.
