Texas Instruments
LMH6882SQE/NOPB
LMH6882SQE/NOPB
Regular price
$4.84 USD
Regular price
Sale price
$4.84 USD
Unit price
per
Couldn't load pickup availability
LMH6882SQE/NOPB Texas Instruments - Yeehing Electronics
2.4 GHz Dual Programmable Differential Amplifier with Gain Control
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 11.474 |
| 100 — 249 | 10.022 |
| 250 — 999 | 7.728 |
| 1,000 + | 4.84 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Differential Amplifiers |
| RoHS | Y |
| Series | LMH6882 |
| Number of Channels | 2 Channel |
| GBP - Gain Bandwidth Product | 2.4 GHz |
| SR - Slew Rate | 6 kV/us |
| CMRR - Common Mode Rejection Ratio | - 40 dB |
| Operating Supply Current | 270 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | WQFN-36 |
| Packaging | Reel |
| Amplifier Type | VGA |
| Product | Differential Amplifiers |
| Brand | Texas Instruments |
| Input Voltage Range - Max | 5.25 V |
| Gain V/V | 2 V/V |
| Maximum Input Resistance | 100 Ohms |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 4.75 V to 5.25 V |
| Product Type | Differential Amplifiers |
| Factory Pack Quantity | 250 |
| Subcategory | Amplifier ICs |
| Unit Weight | 0.003122 oz |
For more information, please refer to datasheet
Documents
| LMH6882SQE/NOPB Datasheet |
More Information
The LMH6882 is a high-speed, high-performance programmable differential amplifier. With a bandwidth of 2.4 GHz and high linearity of 42 dBm OIP3, the LMH6882 is suitable for a wide variety of signal conditioning applications.
