LMK00338RTAR Texas Instruments - Yeehing Electronics
8-output PCIe® Gen1/Gen2/Gen3/Gen4/Gen5 clock buffer and level translator
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 2.854 |
100 — 249 | 2.501 |
250 — 999 | 1.754 |
1,000 + | 0.82 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Clock Buffer |
RoHS | Y |
Series | LMK00338 |
Number of Outputs | 8 Output |
Maximum Input Frequency | 400 MHz |
Propagation Delay - Max | 2700 ps |
Supply Voltage - Max | 3.45 V |
Supply Voltage - Min | 3.15 V |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 85 C |
Mounting Style | SMD/SMT |
Package / Case | WQFN-40 |
Packaging | Reel |
Input Type | CML, HCSL, HSTL, LVCMOS, LVDS, LVPECL, LVTTL, SSTL, XTAL |
Output Type | HCSL, LVCMOS |
Brand | Texas Instruments |
Duty Cycle - Max | 55 % |
Max Output Freq | 400 MHz |
Moisture Sensitive | Yes |
Operating Supply Current | 13.5 mA |
Product Type | Clock Buffer |
Factory Pack Quantity | 1000 |
Subcategory | Clock & Timer ICs |
Unit Weight | 0.001929 oz |
For more information, please refer to datasheet
Documents
LMK00338RTAR Datasheet |
More Information
The LMK00338 device is an 8-output PCIe Gen1/Gen2/Gen3/Gen4/Gen5 fanout buffer intended for high-frequency, low-jitter clock, data distribution, and level translation. The input clock can be selected from two universal inputs or one crystal input. The selected input clock is distributed to two banks of 4 HCSL outputs and one LVCMOS output. The LVCMOS output has a synchronous enable input for runt-pulse-free operation when enabled or disabled. The LMK00338 operates from a 3.3-V core supply and 3 independent 3.3-V or 2.5-V output supplies.
