LMK00804BQWRGTTQ1


YeeHing #: Y003-LMK00804BQWRGTTQ1
Inventory: 5600

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

LMK00804BQWRGTTQ1 Texas Instruments - Yeehing Electronics

Automotive, 1.5-V to 3.3-V, 1-to-4 high-performance LVCMOS fanout buffer & level translator

Pricing (USD)

Quantity Unit Price
1 — 99 6.291
100 — 249 5.129
250 — 999 4.031
1,000 + 2.39

The above prices are for reference only.

Specifications

None

For more information, please refer to datasheet

Documents

LMK00804BQWRGTTQ1 Datasheet

More Information

The LMK00804B-Q1 is a high-performance clock fan-out buffer and level translator that can distribute up to four LVCMOS/LVTTL outputs (3.3-V, 2.5-V, 1.8-V, or 1.5-V levels) from one of two selectable inputs that can accept differential or single-ended inputs. The clock enable input is synchronized internally to eliminate runt or glitch pulses on the outputs when the clock enable terminal is asserted or deasserted. The outputs are held in logic low state when the clock is disabled. The LMK00804B-Q1 can also distribute a low-jitter clock across four transceivers and can improve the overall target detection and resolution in a cascaded mmWave radar system.
