LP2996LQ/NOPB Texas Instruments - Yeehing Electronics

1.5A DDR termination regulator with shutdown pin for DDR2

Pricing (USD)

Quantity	Unit Price
1 — 99	1.366
100 — 249	1.129
250 — 999	0.811
1,000 +	0.49

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Minimum Operating Temperature	0
Maximum Operating Temperature	125
Factory Pack Quantity	1,000
Package | Pins	WQFN (NHP) | 16

For more information, please refer to datasheet

Documents

LP2996LQ/NOPB Datasheet

More Information

The LP2996-N and LP2996A linear regulators are designed to meet the JEDEC SSTL-2 specifications for termination of DDR-SDRAM. The device also supports DDR2, while LP2996A supports DDR3 and DDR3L VTT bus termination with VDDQ minimum of 1.35 V. The device contains a high-speed operational amplifier to provide excellent response to load transients. The output stage prevents shoot through while delivering 1.5-A continuous current and transient peaks up to 3 A in the application as required for DDR-SDRAM termination. The LP2996-N and LP2996A also incorporate a VSENSE pin to provide superior load regulation and a VREF output as a reference for the chipset and DIMMs.
