LP2996MRX/NOPB Texas Instruments - Yeehing Electronics
1.5A DDR termination regulator with shutdown pin for DDR2
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 1.138 |
100 — 249 | 0.94 |
250 — 999 | 0.675 |
1,000 + | 0.36 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Power Management Specialized - PMIC |
RoHS | Y |
Output Voltage Range | 900 mV |
Output Current | 1.5 A |
Input Voltage Range | 1.8 V to 5.5 V |
Input Current | 320 uA |
Minimum Operating Temperature | 0 C |
Maximum Operating Temperature | + 125 C |
Mounting Style | SMD/SMT |
Package / Case | SO-PowerPad-8 |
Type | Linear Regulator |
Packaging | Reel |
Operating Temperature Range | 0 C to + 125 C |
Series | LP2996-N |
Brand | Texas Instruments |
Operating Supply Current | 320 uA |
Operating Supply Voltage | 1.8 V to 5.5 V |
Product Type | Power Management Specialized - PMIC |
Factory Pack Quantity | 2500 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.002490 oz |
For more information, please refer to datasheet
Documents
LP2996MRX/NOPB Datasheet |
More Information
The LP2996-N and LP2996A linear regulators are designed to meet the JEDEC SSTL-2 specifications for termination of DDR-SDRAM. The device also supports DDR2, while LP2996A supports DDR3 and DDR3L VTT bus termination with VDDQ minimum of 1.35 V. The device contains a high-speed operational amplifier to provide excellent response to load transients. The output stage prevents shoot through while delivering 1.5-A continuous current and transient peaks up to 3 A in the application as required for DDR-SDRAM termination. The LP2996-N and LP2996A also incorporate a VSENSE pin to provide superior load regulation and a VREF output as a reference for the chipset and DIMMs.
