LP38500ATJ-ADJ/NOPB


YeeHing #: Y012-LP38500ATJ-ADJ/NOPB
Inventory: 5000

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

LP38500ATJ-ADJ/NOPB Texas Instruments - Yeehing Electronics

1.5-A, adjustable ultra-low-dropout voltage regulator

Pricing (USD)

Quantity Unit Price
1 — 99 1.579
100 — 249 1.304
250 — 999 0.937
1,000 + 0.49

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category LDO Voltage Regulators
RoHS Y
Mounting Style SMD/SMT
Package / Case TO-263-5
Output Voltage 600 mV to 5 V
Output Current 1.5 A
Number of Outputs 1 Output
Polarity Positive
Input Voltage MAX 5.5 V
Input Voltage MIN 2.7 V
Output Type Adjustable
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 125 C
Dropout Voltage 220 mV
Series LP38500-ADJ
Packaging Reel
Operating Temperature Range - 40 C to + 125 C
Product LDO Linear Regulators
Tolerance 1.5 %
Type LDO Linear Regulator
Brand Texas Instruments
Dropout Voltage - Max 0.275 V at 1.5 A
PSRR / Ripple Rejection - Typ 58 dB
Voltage Regulation Accuracy +/- 1.5 %
Line Regulation 0.04 %/V
Load Regulation 0.18 %/A
Operating Supply Current 2 mA
Product Type LDO Voltage Regulators
Factory Pack Quantity 1000
Subcategory PMIC - Power Management ICs
Unit Weight 0.044103 oz

For more information, please refer to datasheet

Documents

LP38500ATJ-ADJ/NOPB Datasheet

More Information

TI’s FlexCap low-dropout (LDO) linear regulators feature unique compensation that allow use of any type of output capacitor with no limits on minimum or maximum equivalent series resistance (ESR). The LP38500 and LP38502 series of LDOs operates from a 2.7-V to 5.5-V input supply. These ultra-low-dropout linear regulators respond very quickly to step changes in load, making them suitable for low-voltage microprocessor applications. Developed on a CMOS process (utilizing a PMOS pass transistor) the LP38500-ADJ and LP38502-ADJ have low quiescent currents that changes little with load current.
