Description
M430FR5989SRGCREP Texas Instruments - Yeehing Electronics
16 MHz ULP microcontroller reaturing 128 KB FRAM, 2 KB SRAM, 48 IO, ADC12, Scan IF, AES
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 19.063 |
100 — 249 | 16.652 |
250 — 999 | 12.839 |
1,000 + | 8.04 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | 16-bit Microcontrollers - MCU |
RoHS | Y |
Mounting Style | SMD/SMT |
Package / Case | VQFN-64 |
Series | MSP430FR5989 |
Core | MSP430 |
Data Bus Width | 16 bit |
Maximum Clock Frequency | 16 MHz |
Program Memory Size | 128 kB |
Data RAM Size | 2 kB |
ADC Resolution | 12 bit |
Operating Supply Voltage | 1.8 V to 3.6 V |
Minimum Operating Temperature | - 55 C |
Maximum Operating Temperature | + 95 C |
Packaging | Reel |
Product | MCU |
Program Memory Type | FRAM |
Brand | Texas Instruments |
Data RAM Type | RAM |
Interface Type | I2C, SPI, UART |
Moisture Sensitive | Yes |
Number of ADC Channels | 16 Channel |
Number of Timers/Counters | 5 x 16 bit |
Product Type | 16-bit Microcontrollers - MCU |
Factory Pack Quantity | 2000 |
Subcategory | Microcontrollers - MCU |
Supply Voltage - Max | 3.6 V |
Supply Voltage - Min | 1.8 V |
Watchdog Timers | No Watchdog Timer |
For more information, please refer to datasheet
Documents
M430FR5989SRGCREP Datasheet |
More Information
The MSP430™ ultra-low-power (ULP) FRAM platform combines uniquely embedded FRAM and a holistic ultra-low-power system architecture, allowing innovators to increase performance at lowered energy budgets. FRAM technology combines the speed, flexibility, and endurance of SRAM with the stability and reliability of flash at much lower power.
