PCA9544ARGYR Texas Instruments - Yeehing Electronics

4-channel 2.3- to 5.5-V I2C/SMBus multiplexer with interrupt & voltage translation

Pricing (USD)

Quantity	Unit Price
1 — 99	1.725
100 — 249	1.425
250 — 999	1.023
1,000 +	0.45

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Switch ICs - Various
RoHS	Y
Product	Bidirectional Translating Switches
Number of Switches	4 Switch
Configuration	-
On Resistance - Max	45 Ohms
Operating Supply Voltage	2.3 V to 5.5 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	VQFN-20
Packaging	Reel
Bandwidth	-
Height	0.8 mm
Length	4.5 mm
Series	PCA9544A
Width	3.5 mm
Brand	Texas Instruments
Supply Current - Max	12 uA
Moisture Sensitive	Yes
Pd - Power Dissipation	400 mW
Product Type	Switch ICs - Various
Factory Pack Quantity	3000
Subcategory	Switch ICs
Supply Voltage - Max	5.5 V
Supply Voltage - Min	2.3 V
Unit Weight	0.001517 oz

For more information, please refer to datasheet

Documents

PCA9544ARGYR Datasheet

More Information

The PCA9544A is a 4-channel, bidirectional translating multiplexer controlled via the I2C bus. The SCL/SDA upstream pair fans out to four downstream pairs, or channels. One SCL/SDA pair can be selected at a time, and this is determined by the contents of the programmable control register. Four interrupt inputs ( INT3– INT0), one for each of the downstream pairs, are provided. One interrupt output ( INT) acts as an AND of the four interrupt inputs.
