PCM1774RGPT


YeeHing #: Y002-PCM1774RGPT
Inventory: 7000

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

PCM1774RGPT Texas Instruments - Yeehing Electronics

93dB SNR Low-Power Stereo DAC with HP Amplifier (S/W Control)

Pricing (USD)

Quantity Unit Price
1 — 99 2.909
100 — 249 2.549
250 — 999 1.787
1,000 + 1.01

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Audio D/A Converter ICs
RoHS Y
Series PCM1774
Number of Converters 2 Converter
Resolution 16 bit
Interface Type I2C, SPI
Sampling Rate 50 kS/s
SNR - Signal to Noise Ratio 93 dB
Number of DAC Outputs 2 Output
Operating Supply Voltage 3.3 V
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Mounting Style SMD/SMT
Package / Case QFN-20
Packaging Reel
Description/Function 93DB SNR LOW-POWER STEREO DAC WITH HP AMPLIFIER (S/W CONTROL)
Height 0.93 mm
Length 4 mm
Output Type Voltage
Product Audio DACs
Supply Type Analog and Digital
Width 4 mm
Architecture Delta-Sigma
Brand Texas Instruments
Number of Channels 2 Channel
THD plus Noise 0.002 %
Moisture Sensitive Yes
Number of DACs 2 DAC
Operating Supply Current 10 mA
Polarity Bipolar
Product Type Audio D/A Converter ICs
Factory Pack Quantity 250
Subcategory Audio ICs
Supply Voltage - Max 3.6 V
Supply Voltage - Min 2.4 V
Unit Weight 0.001764 oz

For more information, please refer to datasheet

Documents

PCM1774RGPT Datasheet

More Information

The PCM1774 is a low-power stereo DAC designed for portable digital audio applications. The device integrates headphone amplifier, line amplifier, line input, boost amplifier, programmable gain control, analog mixing, and sound effects. It is available in a small-footprint, 4-mm × 4-mm QFN package. The PCM1774 supports right-justified, left-justified, I2S, and DSP formats, providing easy interfacing to audio DSP and decoder/encoder chips. Sampling rates up to 50 kHz are supported. The user-programmable functions are accessible through a two- or three-wire serial control port.
