Description
REF3330AIRSER Texas Instruments - Yeehing Electronics
30-ppm/°C drift, 3.9µA, 3-pin SOT-23, 3-pin SC70, 8-pin UQFN series voltage reference
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 1.344 |
100 — 249 | 1.11 |
250 — 999 | 0.797 |
1,000 + | 1.58 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Voltage References |
RoHS | Y |
Mounting Style | SMD/SMT |
Package / Case | UQFN-8 |
Reference Type | Series References |
Output Voltage | 3 V |
Initial Accuracy | 0.15 % |
Temperature Coefficient | 30 PPM / C |
Series VREF - Input Voltage - Max | 5.5 V |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 125 C |
Series | REF3330 |
Packaging | Reel |
Operating Temperature Range | - 40 C to + 125 C |
Brand | Texas Instruments |
Operating Supply Current | 3.9 uA |
Product Type | Voltage References |
Factory Pack Quantity | 5000 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.000187 oz |
For more information, please refer to datasheet
Documents
REF3330AIRSER Datasheet |
More Information
The REF33xx is a low-power, precision, low-dropout voltage reference family available in tiny SC70-3 and SOT-23-3 packages, and in a 1.5-mm × 1.5-mm UQFN-8 package. Small size and low power consumption (5-µA max) make the REF33xx ideal for a wide variety of portable and battery-powered applications.
